Le Meitner MA-1 est un dac extrêmement précis et dépourvu de toute coloration audible.
Il procure une image quasi "palpable" et parfaitement détourée.
Spécifications techniques :
The Meitner MA-1 V2: • Supports audio at sample rates of 44.1, 48, 88.2, 96, 176.4, 192kHz and DSD through all 6 digital inputs • Supports DSD128/2xDSD and DXD streaming over USB Audio • Complies with the USB Class 2 audio interface standard • Is simple to use. There's nothing to configure. Just plug and play.
MFAST™ asynchronous technology Feed the MA-1 V2 through any of its six inputs and the Meitner Frequency Acquisition System (MFAST™) instantly acquires the signal, buffers it, then strips jitter out completely. A high-speed asynchronous system, it decouples input from output. MFAST™ ensures that you’ll enjoy pristine sonic clarity whether the incoming data stream is pure or anything but.
MDAT™: 8x DSD upsampling From there, the signal goes straight into the newly updated Meitner Digital Audio Translator (MDAT2™) which upsamples digital audio to DSD512/8xDSD, eight times the SACD standard sampling rate.
The world's best dac/clock combination Our MA-1 V2 features the updated MDAC™ dual differential discrete D-to-A and MCLK™ high-purity master clock modules. Together, they’re music to our ears. Yours too, as an audition will quickly prove.
The Meitner MA-1 V2 Stereo D/A Converter. It may be the first audio product that’s equally appealing to those on a budget, and those with no budget limitations at all.
Key Features & Specifications:
• Supports audio at sample rates of 44.1, 48, 88.2, 96, 176.4 and 192kHz plus DSD through all 6 inputs:• 1 x USB• 1 x AES/EBU• 2 x TOSLINK S/PDIF• 2 x COAX S/PDIF• Supports 2xDSD (via DoP) and DXD streaming over USB Audio• MFAST™ asynchronous technology for instant signal acquisition, jitter-free performance• MDAT2™ signal processing technology:• Provides DSD512/8xDSD upsampling for PCM and DSD audio• Preserves phase, frequency and dynamic integrity of the waveform• MDAC™ discrete dual differential D-to-A conversion circuit• MCLK™ high-purity master clock that establishes new benchmarks in jitter performance• Galvanically isolated USB Audio interface• USB service port for future software upgrades• Sleek credit-card style remote and serial port for wired remote control• Power supply:• Power factor corrected• Universal 90V-260V, 50/60Hz• Power consumption: max. 50W• CE Approved Stereo analog outputs:
Balanced (XLR) and Unbalanced (RCA)Output voltage (with 0dBfs input):• XLR outputs: 4.6Vrms (+15.4dBu)• RCA outputs: 2.3Vrms (+9.4dBu)Output impedance:• 300 ohms balanced (XLR)• 150 ohms unbalanced (RCA) Dimensions W x D x H: 435 x 400 x 92mmWeight: 7.43 kg/16.39 lbs net with remote control Designed and Manufactured in Canada.
